Number systems in other bases.

Objectives

1. Examine number systems in different bases.

Notes

• In the last notes we discussed our base ten positional number system.
• I am really not interested in positionless number systems, or even semi-positional number systems (think Roman numerals)
• But I am interested in the base 10.
• What if we were in the world of Futurama?
  • In this episode the Robot Devil and Fry exchange hands
  • It looks like Fry's hand has three fingers and a thumb.
  • And the Robot devil's "hand" has three fingers.
  • I think this is true throughout the series.
  • I also think it is common for cartoons to have less than 4 fingers and a thumb.
• Let's assume four digits per hand.
  • In the naive counting on your hand system we could have the following

    Fingers	Value
    f		1
    ff		2
    fff		3
    ffft		4
    ffftf		5
    ffftff		6
    ffftfff		7
    ffftffft		8

  • Note we would then be out of "digits" so we would have to start over again.
  • In this is a base 8 system.
  • We will need to do a switch, remember on our fingers in base 10 we went from 0 to 9.
  • In this system we will go from 0 to 7.
  • Or use the digits {0, 1, 2, 3, 4, 5, 6, 7}
• Just a note, if we have a number without a subscript, it is base 10, for ALL other systems will will need to write a subscript.
  • OR IT IS WRONG.
  • So count to 15 in base 8.
    • $0_8, 1_8, 2_8, 3_8, 3_8, 5_8, 6_8, 7_8$
    • But the next number is 8 (base 10).
    • But we don't have a symbol for 8 in base 8, so what do we do?
      • Naive approach, $10_8$, because that is what we did in base 10?
      • $10_8 = 1x8^1 + 0x8^0$ = 8 + 0 = 8 (base 10)
    • What is $11_8$,
      • naive - 9 because it comes after 8.
      • $11_8 = 1x8^1 + 1x8^0$ = 8+1 = 9
    • So continuing on $10_8 = 8, 11_8 = 9, 12_8 = 10, 13_8 = 11, 14_8 = 12, 15_8 = 13, 16_8 = 14, 17_8 = 15$
    • But what about 16, that is 2x8 so 16 = $20_8$
• Base 8 is not special, nor is base 10.
  • We are more comfortable in base 10.
  • We will use base 8, somewhat, later.
• How about the Robot Devil?
  • He has six digits total, so he might natively use base 6.
  • digits = {0,1,2,3,4,5}
  • What does $10_6$ represent?
  • How about $15_6$
  • How about $21_6$
• In general if we are in base b,
  • Digits = {0, 1, 2, 3, ... b-1}
    • If we need digits past 9, we generally use a, b, c, d, ...
    • $a_{16} = 10, f_{16} = 16$
  • ${a_{n-1}a_{n-2}...a_0}_b = a_{n-1}xb^{n-1} + a_{n-2}xb^{n-2} + ... + a_1b^1+a_0b^0$
    • $21341_5 = 2x5^4 + 1x5^3 + 3x5^2 + 4x5^1 + 1x5^0$
    • $532_7 = 5 x 7^2 + 3x7^1 + 2x7^0$
• For any system like this we need the digits and the base.
• We are interested in
  • Base 10, as that is what we work in
  • Base 2, as that is what most computers work in
  • Base 8, because it is an easy shorthand for base 2
  • Base 16, because it is an easy shorthand for base 2.
• By the way, we learned an algorithm in these notes that you need to know.
  • To convert a number in any base to base 10

    CONVERT-TO-BASE-10
      Input: a string of digits S and an integer base b
             Assume s[n-1] is the most significant digit and s[0] is the least.
      Output: an integer

     let n = length of S
     let sum = 0
     for i = n-1 to 0
        sum = sum + s[i] * pow(base, i)
     return sum
